Product Construction
Backing material | PET cloth |
Total thickness | 260 µm |
Type of adhesive | advanced acrylic |
PET cloth tape for high abrasion protection
tesa® 51036 is a PET cloth wire harness tape with an advanced acrylic adhesive (triple A®).
Major Features:
Backing material | PET cloth |
Total thickness | 260 µm |
Type of adhesive | advanced acrylic |
Backing material | PET cloth |
Total thickness | 260 µm |
Type of adhesive | advanced acrylic |
Elongation at break | 40 % |
Tensile strength | 275 N/cm |
Unwind force (roll width > 9mm) | 11 N/roll (30 m/min) |
Temperature resistance min. | -40 °C |
Abrasion resistance (5mm mandrel, LV312) | Class D |
Temperature resistance max. | 150 °C |
Noise damping (LV312) | Class A |
Unwind force (roll width ≤ 9mm) | 11 N/roll (30 m/min) |
Abrasion resistance (10mm mandrel, LV312) | Class D |
Elongation at break | 40 % |
Tensile strength | 275 N/cm |
Unwind force (roll width > 9mm) | 11 N/roll (30 m/min) |
Temperature resistance min. | -40 °C |
Abrasion resistance (5mm mandrel, LV312) | Class D |
Temperature resistance max. | 150 °C |
Noise damping (LV312) | Class A |
Unwind force (roll width ≤ 9mm) | 11 N/roll (30 m/min) |
Abrasion resistance (10mm mandrel, LV312) | Class D |
Adhesion to steel | 5 N/cm |
Adhesion to steel | 5 N/cm |
Download the files below for more technical details and information on this product.
