Product Construction
Backing material | aluminium foil |
Color of liner | white |
Thickness of liner | 65 µm |
Total thickness | 60 µm |
Type of adhesive | acrylic |
Type of liner | paper |
Conformable 30µm aluminium tape with liner
tesa® 50525 PV1 is a conformable aluminium tape, based on a 30µm aluminium foil and an acrylic adhesive.
Backing material | aluminium foil |
Color of liner | white |
Thickness of liner | 65 µm |
Total thickness | 60 µm |
Type of adhesive | acrylic |
Type of liner | paper |
Backing material | aluminium foil |
Color of liner | white |
Thickness of liner | 65 µm |
Total thickness | 60 µm |
Type of adhesive | acrylic |
Type of liner | paper |
Elongation at break | 5 % |
Tensile strength | 23 N/cm |
Abrasion resistance | good |
Easy to remove | no |
Temperature resistance min. | -40 °C |
Operation temperature from | -40 °C |
Operation temperature up to | 160 °C |
Backing appearance (visual) | reflective |
Water resistance | very good |
Hand tearability | yes |
Elongation at break | 5 % |
Tensile strength | 23 N/cm |
Abrasion resistance | good |
Easy to remove | no |
Temperature resistance min. | -40 °C |
Operation temperature from | -40 °C |
Operation temperature up to | 160 °C |
Backing appearance (visual) | reflective |
Water resistance | very good |
Hand tearability | yes |
Adhesion to Backing | 4 N/cm |
Adhesion to Steel | 5 N/cm |
Adhesion to Backing | 4 N/cm |
Adhesion to Steel | 5 N/cm |
Download the files below for more technical details and information on this product.
