Product Construction
| Backing material | PET film |
| Colour | transparent |
| Colour of liner | transparent |
| Thickness of liner | 50 µm |
| Thickness of tape | 40 µm |
| Total thickness | 40 µm |
| Type of adhesive | acrylic |
| Type of liner | PET |
tesa® 66514
Optical Clear Display Protection Film
Product Features
- High transparency providing excellent visibility of final display.
- Secure protection of display surfaces.
- Easy peel-off release liner with good die-cut abilities.
Product description
tesa® 66514 is a single coated adhesive tape used for the protection of high gloss LCD display hard lenses of electronic and communication devices during assembly, inspection, storage and transport.
The tape consists of a PET backing coated with an acrylic adhesive. It is equipped with a transparent 50µm PET release liner providing easy peel-off.
Product details and specifications
Product Features
- High transparency providing excellent visibility of final display.
- Secure protection of display surfaces.
- Easy peel-off release liner with good die-cut abilities.
- Suitable to various smooth surfaces like Glass, ABS or PC.
- Easy to remove even after long cycle applications.
- 300h weathering resistance according ISO 4892-2.
Application Fields
Protection of high gloss LCD display hard lenses of electronic and communication devices during assembly, inspection, storage and transport.
Product Construction
| Backing material | PET film |
| Colour | transparent |
| Colour of liner | transparent |
| Thickness of liner | 50 µm |
| Thickness of tape | 40 µm |
| Total thickness | 40 µm |
| Type of adhesive | acrylic |
| Type of liner | PET |
Properties / Performance Values
| Easy to remove | yes |
| Suitable for die cutting | yes |
Properties / Performance Values
| Easy to remove | yes |
| Suitable for die cutting | yes |
Adhesion to Values
| Adhesion to ABS (initial) | 0.1 N/cm |
| Adhesion to ABS (after 14 days) | 0.1 N/cm |
| Adhesion to Glass (initial) | 0.1 N/cm |
| Adhesion to Glass (after 14 days) | 0.1 N/cm |
| Adhesion to PC (initial) | 0.1 N/cm |
| Adhesion to PC (after 14 days) | 0.1 N/cm |
| Adhesion to Steel (initial) | 0.1 N/cm |
| Adhesion to Steel (after 14 days) | 0.1 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) | 0.1 N/cm |
| Adhesion to ABS (after 14 days) | 0.1 N/cm |
| Adhesion to Glass (initial) | 0.1 N/cm |
| Adhesion to Glass (after 14 days) | 0.1 N/cm |
| Adhesion to PC (initial) | 0.1 N/cm |
| Adhesion to PC (after 14 days) | 0.1 N/cm |
| Adhesion to Steel (initial) | 0.1 N/cm |
| Adhesion to Steel (after 14 days) | 0.1 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
