Product Construction
| Backing material | PET cloth |
| Total thickness | 260 µm |
| Type of adhesive | advanced acrylic |
tesa® 51036 PV2
PET cloth tape for high abrasion protection
Product Features
- High temperature resistance 150°C/3000h
- High abrasion resistance
- High flag resistance
Product description
tesa® 51036 is a PET cloth wire harness tape with a solvent-free, advanced acrylic adhesive (triple A®).
Color: Black / Orange2
Product details and specifications
Product Features
- High temperature resistance 150°C/3000h
- High abrasion resistance
- High flag resistance
Application Fields
tesa® 51036 is designed for the engine compartment, providing high abrasion protection.
Product Construction
| Backing material | PET cloth |
| Total thickness | 260 µm |
| Type of adhesive | advanced acrylic |
Properties / Performance Values
| Elongation at break | 40 % |
| Tensile strength | 275 N/cm |
| Temperature resistance min. | -40 °C |
| Abrasion resistance (5mm mandrel, LV312) | Class D |
| Temperature resistance max. | 150 °C |
| Unwind force (roll width ≤ 9mm) | 11 N/roll (30 m/min) |
| Abrasion resistance (10mm mandrel, LV312) | Class D |
| Unwind force (roll width > 9mm) | 11 N/roll (30 m/min) |
| Noise damping (LV312) | Class A |
Properties / Performance Values
| Elongation at break | 40 % |
| Tensile strength | 275 N/cm |
| Temperature resistance min. | -40 °C |
| Abrasion resistance (5mm mandrel, LV312) | Class D |
| Temperature resistance max. | 150 °C |
| Unwind force (roll width ≤ 9mm) | 11 N/roll (30 m/min) |
| Abrasion resistance (10mm mandrel, LV312) | Class D |
| Unwind force (roll width > 9mm) | 11 N/roll (30 m/min) |
| Noise damping (LV312) | Class A |
Adhesion to Values
| Adhesion to steel | 3 N/cm |
Adhesion to Values
| Adhesion to steel | 3 N/cm |
Additional Info
Standard widths: 9, 19, 25, 32 mm
Standard lengths: 25 m
1 PV2: global version
2 similar to RAL 2003
Standard lengths: 25 m
- Further dimensions are available upon request
- Standard core diameter: 38 mm
1 PV2: global version
2 similar to RAL 2003
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
