Product Construction
Backing material | PET |
Color of liner | white/red logo |
Total thickness | 2.87 mils
73 µm |
Type of adhesive | type: tackified acrylic |
Type of liner | type: glassine |
Weight of liner | 98.14 lbs/in²
69 g/m² |
tesa® 58351 is a 73 μm/2.9 mils single-sided transparent PET filmic tape.
The tackified acrylic adhesive gives this product a very good peel strength and outstanding anti-repulsion property. The 23um/.90 mils transparent PET filmic backing offers excellent electrical insulation property. The glassine liner ensures it can be easily released without adhesive residue. It can meet the strict automotive environmental and long-term durability requirement.
Backing material | PET |
Color of liner | white/red logo |
Total thickness | 2.87 mils
73 µm |
Type of adhesive | type: tackified acrylic |
Type of liner | type: glassine |
Weight of liner | 98.14 lbs/in²
69 g/m² |
Backing material | PET |
Color of liner | white/red logo |
Total thickness | 2.87 mils
73 µm |
Type of adhesive | type: tackified acrylic |
Type of liner | type: glassine |
Weight of liner | 98.14 lbs/in²
69 g/m² |
Dielectric breakdown voltage | 6.5 V |
Humidity resistance | very good |
Dielectric breakdown voltage | 6.5 V |
Humidity resistance | very good |
Adhesion to Aluminium (initial) | 2.57 lbs/in
4.5 N/cm |
Adhesion to Aluminium (after 14 days) | 3.6 lbs/in
6.3 N/cm |
Adhesion to PC (initial) | 1.88 lbs/in
3.3 N/cm |
Adhesion to PC (after 14 days) | 3.43 lbs/in
6 N/cm |
Adhesion to Steel (initial) | 2.86 lbs/in
5 N/cm |
Adhesion to Steel (after 14 days) | 4.51 lbs/in
7.9 N/cm |
Adhesion to Aluminium (initial) | 2.57 lbs/in
4.5 N/cm |
Adhesion to Aluminium (after 14 days) | 3.6 lbs/in
6.3 N/cm |
Adhesion to PC (initial) | 1.88 lbs/in
3.3 N/cm |
Adhesion to PC (after 14 days) | 3.43 lbs/in
6 N/cm |
Adhesion to Steel (initial) | 2.86 lbs/in
5 N/cm |
Adhesion to Steel (after 14 days) | 4.51 lbs/in
7.9 N/cm |
Download the files below for more technical details and information on this product.
