Product Construction
| Adhesive Type | acrylic |
| Backing material | PET film |
| Color | transparent |
| Total thickness | 50 µm |
tesa® 4129
Transparent, single-sided tape for splicing of filmic materials, litho mounting or edge protection and reinforcement
Product Features
- The thin high-temperature tape conforms well around irregular shapes and its acrylic adhesive system combines good initial tack with high shear strength and provides a high short-term temperature resistance of 200°C.
- tesa® 4129 is resistant to humidity and most chemicals.
- High resistance to humidity and chemicals
Product description
tesa® 4129 is a transparent, single-sided tape featuring a polyester backing with an acrylic adhesive. tesa® 4129 is used for various applications, especially for splicing of filmic materials, litho mounting or edge protection and reinforcement.
Product details and specifications
Product Features
- The thin high-temperature tape conforms well around irregular shapes and its acrylic adhesive system combines good initial tack with high shear strength and provides a high short-term temperature resistance of 200°C.
- tesa® 4129 is resistant to humidity and most chemicals.
- High resistance to humidity and chemicals
- High short-term temperature resistance (200°C)
- Thin tape design for good conformability
Application Fields
- tesa® 4129 is recommended for splicing of filmic materials, e.g. photographic negatives
- The high-temperature tape can withstand temperatures of 200°C (short-term)
- tesa® 4129 can be used for litho mounting or edge protection and reinforcement applications
Product Construction
| Adhesive Type | acrylic |
| Backing material | PET film |
| Color | transparent |
| Total thickness | 50 µm |
Properties / Performance Values
| Elongation at break | 140 % |
Properties / Performance Values
| Elongation at break | 140 % |
Adhesion to Values
| Adhesion to Steel | 2.3 N/cm |
Adhesion to Values
| Adhesion to Steel | 2.3 N/cm |
Additional Info
- Dielectric Strength according to DIN EN 60243-1: 90,4 kV/mm
- Surface resistivity according to DIN IEC 60093: 4,45E+14 Ω
- Volume resistivity according to DIN IEC 60093: 7,36E+15 Ωcm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
