Product Construction
| Adhesive Type | water-based acrylic |
| Backing material | none |
| Color | transparent |
| Color of liner | yellow |
| Liner Type | glassine |
| Thickness of liner | 80 µm |
| Thickness of tape | 100 µm |
tesa® 52110
100 µm double sided transfer tape for lamination and converting applications
Product Features
- High initial tack and peel adhesion
- Very good bonding strength to a wide variety of substrates
- Good die-cutting properties
Product description
tesa® 52110 is a conformable transfer tape, equipped with a water-based acrylic adhesive and a thickness of 100 µm. The water-based acrylic adhesive is temperature resistant up to 180°C and offers very good bonding strength on various substrates. tesa® 52110 was specifically developed for all kinds of lamination and converting applications. Due to its low emission values, it is classified as ultra low VOC and particularly suited to meet interior requirements, e.g. in the automotive industry.
tesa® 52110 is available in efficient laminating lengths and widths as well as in a 50 µm version (tesa® 52105).
Product details and specifications
Product Features
- High initial tack and peel adhesion
- Very good bonding strength to a wide variety of substrates
- Good die-cutting properties
- Highly conformable to follow difficult 3D shapes
- Ultra low total VOC concentration according to VDA 278 analysis
Application Fields
tesa® 52110 is suitable for various types of lamination and converting applications.
Key applications include:
Key applications include:
- Lamination of insulation materials
- Mounting of flooring systems
- Lamination of foam for HVAC (heating, ventilation, and air conditioning) seals
- Bonding of fleece and felt substrates as well as decorative fabrics
- Laminates for NVH (noise, vibration, and harshness) and BSR (buzz, squeak, and rattle) prevention
Product Construction
| Adhesive Type | water-based acrylic |
| Backing material | none |
| Color | transparent |
| Color of liner | yellow |
| Liner Type | glassine |
| Thickness of liner | 80 µm |
| Thickness of tape | 100 µm |
Properties / Performance Values
| Temperature resistance short term | 100 °C |
| Humidity resistance | good |
| Ageing resistance (UV) | very good |
| Suitable for rough surfaces | very good |
| Fogging | very good |
| Temperature resistance max. | 180 °C |
Properties / Performance Values
| Temperature resistance short term | 100 °C |
| Humidity resistance | good |
| Ageing resistance (UV) | very good |
| Suitable for rough surfaces | very good |
| Fogging | very good |
| Temperature resistance max. | 180 °C |
Adhesion to Values
| Adhesion to PP (initial) | 5.1 N/cm |
| Adhesion to PP (after 14 days) | 6.8 N/cm |
| Adhesion to Steel (initial) | 9.2 N/cm |
| Adhesion to Steel (after 14 days) | 11.6 N/cm |
Adhesion to Values
| Adhesion to PP (initial) | 5.1 N/cm |
| Adhesion to PP (after 14 days) | 6.8 N/cm |
| Adhesion to Steel (initial) | 9.2 N/cm |
| Adhesion to Steel (after 14 days) | 11.6 N/cm |
Additional Info
According to VDA278 analysis tesa® 52110 does not contain any single substances restricted by the drafted GB regulations (China) as well as the indoor concentration guideline by Health, Labour and Welfare Ministry (Japan).
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
