Product Construction
Adhesive Type | tackified acrylic |
Backing material | PET film |
Color | transparent |
Color of liner | brown |
Liner Type | glassine |
Thickness of liner | 69 µm |
Total thickness | 30 µm |
Weight of liner | 80 g/m² |
30µm double sided transparent film tape
tesa® 68590 is a transparent, double-sided self-adhesive tape consisting of a PET backing and a tackified acrylic adhesive.
Adhesive Type | tackified acrylic |
Backing material | PET film |
Color | transparent |
Color of liner | brown |
Liner Type | glassine |
Thickness of liner | 69 µm |
Total thickness | 30 µm |
Weight of liner | 80 g/m² |
Adhesive Type | tackified acrylic |
Backing material | PET film |
Color | transparent |
Color of liner | brown |
Liner Type | glassine |
Thickness of liner | 69 µm |
Total thickness | 30 µm |
Weight of liner | 80 g/m² |
Elongation at break | 50 % |
Tensile strength | 7 N/cm |
Temperature resistance long term | 100 °C |
Ageing resistance (UV) | very good |
Static shear resistance at 23°C | good |
Humidity resistance | very good |
Temperature resistance short term | 200 °C |
Elongation at break | 50 % |
Tensile strength | 7 N/cm |
Temperature resistance long term | 100 °C |
Ageing resistance (UV) | very good |
Static shear resistance at 23°C | good |
Humidity resistance | very good |
Temperature resistance short term | 200 °C |
Adhesion to ABS (initial) | 5.8 N/cm |
Adhesion to ABS (after 14 days) | 7.4 N/cm |
Adhesion to Aluminium (initial) | 5.5 N/cm |
Adhesion to Aluminium (after 14 days) | 8.2 N/cm |
Adhesion to Glass (initial) | 7.1 N/cm |
Adhesion to Glass (after 14 days) | 8.7 N/cm |
Adhesion to PC (initial) | 6.9 N/cm |
Adhesion to PC (after 14 days) | 8.4 N/cm |
Adhesion to Steel (initial) | 6.6 N/cm |
Adhesion to Steel (after 14 days) | 8.1 N/cm |
Adhesion to ABS (initial) | 5.8 N/cm |
Adhesion to ABS (after 14 days) | 7.4 N/cm |
Adhesion to Aluminium (initial) | 5.5 N/cm |
Adhesion to Aluminium (after 14 days) | 8.2 N/cm |
Adhesion to Glass (initial) | 7.1 N/cm |
Adhesion to Glass (after 14 days) | 8.7 N/cm |
Adhesion to PC (initial) | 6.9 N/cm |
Adhesion to PC (after 14 days) | 8.4 N/cm |
Adhesion to Steel (initial) | 6.6 N/cm |
Adhesion to Steel (after 14 days) | 8.1 N/cm |
Download the files below for more technical details and information on this product.
