Product Construction
| Adhesive Type | acrylic |
| Backing material | none |
| Color | black |
| Color of liner | transparent |
| Liner Type | PET |
| Thickness of liner | 50 µm |
| Total thickness | 150 µm |
| Weight of liner | 72 g/m² |
tesa® 75815
150μm d/s Chemical resistant acrylic foam tape
Product Features
- Thickness: 150μm
- Excellent chemical resistance
- Very high shock performance
Product description
tesa® 75815 is a double-sided black tape. It is equipped with a high shock absorbing and chemical resistant adhesive.
Product details and specifications
Product Features
- Thickness: 150μm
- Excellent chemical resistance
- Very high shock performance
- Good wettability
- High sealing ability with superior waterproof (IPX8)
Application Fields
- Demanding touch panel, lens or screen mounting applications with high requirements for chemical and impact resistance
- Component mounting with high requirements for chemical and impact resistance
- Mounting of 3D or ultra slim bezel designs
- Mounting of waterproof designs
Product Construction
| Adhesive Type | acrylic |
| Backing material | none |
| Color | black |
| Color of liner | transparent |
| Liner Type | PET |
| Thickness of liner | 50 µm |
| Total thickness | 150 µm |
| Weight of liner | 72 g/m² |
Properties / Performance Values
| Ageing resistance (UV) | very good |
Properties / Performance Values
| Ageing resistance (UV) | very good |
Adhesion to Values
| Adhesion to PC (initial) | 9.5 N/cm |
| Adhesion to PC (after 3 days) | 16.5 N/cm |
| Adhesion to Steel (initial) | 8.5 N/cm |
| Adhesion to Steel (after 3 days) | 9.5 N/cm |
Adhesion to Values
| Adhesion to PC (initial) | 9.5 N/cm |
| Adhesion to PC (after 3 days) | 16.5 N/cm |
| Adhesion to Steel (initial) | 8.5 N/cm |
| Adhesion to Steel (after 3 days) | 9.5 N/cm |
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
