Product Construction
Adhesive Type | tackified acrylic |
Backing material | foamed acrylic |
Color | gray |
Total thickness | 1500 µm |
1.5 mm double-sided acrylic foam tape for mounting of automotive exterior parts
tesa® ACXplus 88215 is a 1.5 mm double-sided acrylic foam tape with an unique double layer product design, coated with low surface energy (LSE) adhesive on the covered side. Its high-performance LSE adhesive has excellent initial adhesive properties when it comes to different types of OEM clear coats and can reach near ultimate performance right after the application. Even at temperatures down to 5°C, tesa® ACXplus 88215 shows excellent bonding strength on clear coat.
tesa® ACXplus 88215 is specially recommended for mounting of primer-treated attachment parts including ribbed surfaces to difficult to bond clear coats. Thanks to its viscoelastic acrylic foam core, tesa® ACXplus 88215 has the ability to absorb and dissipate dynamic and static loads.
Also available in thicknesses of 0.8 mm and 1.1 mm.
Main features
Adhesive Type | tackified acrylic |
Backing material | foamed acrylic |
Color | gray |
Total thickness | 1500 µm |
Adhesive Type | tackified acrylic |
Backing material | foamed acrylic |
Color | gray |
Total thickness | 1500 µm |
Ageing resistance (UV) | good |
Temperature resistance long term | 80 °C |
Temperature range | -40 to +80 |
Humidity resistance | very good |
Temperature resistance short term | 120 °C |
Ageing resistance (UV) | good |
Temperature resistance long term | 80 °C |
Temperature range | -40 to +80 |
Humidity resistance | very good |
Temperature resistance short term | 120 °C |
Adhesion to ABS (initial) | 8 N/cm |
Adhesion to ABS (covered side, after 3 days) | 33 N/cm |
Adhesion to ABS (covered side, initial) | 27 N/cm |
Adhesion to ABS (after 3 days) | 13 N/cm |
Adhesion to Clear coat (after 24 hrs) | 31 N/cm |
Adhesion to Clear coat (after 20 min) | 28 N/cm |
Adhesion to Steel (initial) | 12 N/cm |
Adhesion to Steel (covered side, after 3 days) | 37 N/cm |
Adhesion to Steel (covered side, initial) | 31 N/cm |
Adhesion to Steel (after 3 days) | 26 N/cm |
Adhesion to ABS (initial) | 8 N/cm |
Adhesion to ABS (covered side, after 3 days) | 33 N/cm |
Adhesion to ABS (covered side, initial) | 27 N/cm |
Adhesion to ABS (after 3 days) | 13 N/cm |
Adhesion to Clear coat (after 24 hrs) | 31 N/cm |
Adhesion to Clear coat (after 20 min) | 28 N/cm |
Adhesion to Steel (initial) | 12 N/cm |
Adhesion to Steel (covered side, after 3 days) | 37 N/cm |
Adhesion to Steel (covered side, initial) | 31 N/cm |
Adhesion to Steel (after 3 days) | 26 N/cm |
Download the files below for more technical details and information on this product.
