Product Construction
| Adhesive Type | tackified acrylic |
| Backing material | PET film |
| Color | transparent |
| Total thickness | 6.5 mils
165 µm |
tesa® 51865 - Team 4965 Differential
165µm/6.5 mils double sided transparent PET film tape with asymmetrical product design
Product Features
- Asymmetrical product design with superior adhesion on liner covered side
- Excellent bond to extruded trims and profiles
- Reliable bond even on low surface energy surfaces
Product description
- tesa® 51865 - Team 4965 Differential is a transparent, double-sided industrial mounting tape consisting of a PET backing and a tackified acrylic adhesive. The asymmetrical double-sided tape is the differential version of tesa® 4965 Original and its adhesive is based on a patented and protected product technology. The liner covered side of tesa® 51865 - Team 4965 Differential has a high coating weight for maximum flexibility and versatility on multiple surface demands. The open side has a reduced coating weight which delivers a secure bond to flat profiles laminated under controlled conditions. tesa® 51865 - Team 4965 Differential is able to withstand numerous environmental factors such as humidity, UV-light and temperatures of up to 200°C for limited periods of time. The tackified acrylic adhesive makes for an excellent hold on various surfaces, high tack, and good shear strength.
https://www.tesa.com/en-us/industry/general-applications/mounting/team-4965-assortment
Product details and specifications
Product Features
- Asymmetrical product design with superior adhesion on liner covered side
- Excellent bond to extruded trims and profiles
- Reliable bond even on low surface energy surfaces
- Immediate usability right after assembly
- High resistance to demanding environmental conditions
Application Fields
- tesa® 51865 - Team 4965 Differential is especially designed for mounting of extruded trims and profiles
- Mounting of decorative trims and profiles in the furniture industry
- Bonding in the roller blind production
- Mounting of magnetic stripes
Product Construction
| Adhesive Type | tackified acrylic |
| Backing material | PET film |
| Color | transparent |
| Total thickness | 6.5 mils
165 µm |
Properties / Performance Values
| Elongation at break | 55 % |
| Tensile strength | 11.42 lbs/in
20 N/cm |
| Tack | good |
| Softener resistance | good |
| Static shear resistance at 23°C | very good |
| Chemical Resistance | good |
| Temperature resistance short term | 392 °F
200 °C |
| Temperature resistance long term | 212 °F
100 °C |
| Ageing resistance (UV) | good |
| Humidity resistance | very good |
| Static shear resistance at 40°C | very good |
| Temperature resistance min. | -40 °F
-40 °C |
Properties / Performance Values
| Elongation at break | 55 % |
| Tensile strength | 11.42 lbs/in
20 N/cm |
| Tack | good |
| Softener resistance | good |
| Static shear resistance at 23°C | very good |
| Chemical Resistance | good |
| Temperature resistance short term | 392 °F
200 °C |
| Temperature resistance long term | 212 °F
100 °C |
| Ageing resistance (UV) | good |
| Humidity resistance | very good |
| Static shear resistance at 40°C | very good |
| Temperature resistance min. | -40 °F
-40 °C |
Adhesion to Values
| Adhesion to ABS (initial) | 5.42 lbs/in
9.5 N/cm |
| Adhesion to ABS (after 14 days) | 5.71 lbs/in
10 N/cm |
| Adhesion to ABS (covered side, after 14 days) | 7.42 lbs/in
13 N/cm |
| Adhesion to ABS (covered side, initial) | 6.85 lbs/in
12 N/cm |
| Adhesion to Aluminium (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to Aluminium (after 14 days) | 5.42 lbs/in
9.5 N/cm |
| Adhesion to Aluminium (covered side, after 14 days) | 7.14 lbs/in
12.5 N/cm |
| Adhesion to Aluminium (covered side, initial) | 6.85 lbs/in
12 N/cm |
| Adhesion to PC (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PC (after 14 days) | 6.85 lbs/in
12 N/cm |
| Adhesion to PC (covered side, initial) | 7.42 lbs/in
13 N/cm |
| Adhesion to PC (covered side, after 14 days) | 8.57 lbs/in
15 N/cm |
| Adhesion to PE (initial) | 3.71 lbs/in
6.5 N/cm |
| Adhesion to PE (after 14 days) | 4 lbs/in
7 N/cm |
| Adhesion to PE (covered side, after 14 days) | 4.57 lbs/in
8 N/cm |
| Adhesion to PE (covered side, initial) | 4 lbs/in
7 N/cm |
| Adhesion to PET (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PET (after 14 days) | 5.42 lbs/in
9.5 N/cm |
| Adhesion to PET (covered side, after 14 days) | 6 lbs/in
10.5 N/cm |
| Adhesion to PET (covered side, initial) | 5.71 lbs/in
10 N/cm |
| Adhesion to PP (initial) | 4 lbs/in
7 N/cm |
| Adhesion to PP (after 14 days) | 4.57 lbs/in
8 N/cm |
| Adhesion to PP (covered side, after 14 days) | 4.85 lbs/in
8.5 N/cm |
| Adhesion to PP (covered side, initial) | 4.57 lbs/in
8 N/cm |
| Adhesion to PS (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PS (after 14 days) | 6.28 lbs/in
11 N/cm |
| Adhesion to PS (covered side, initial) | 6.85 lbs/in
12 N/cm |
| Adhesion to PS (covered side, after 14 days) | 7.71 lbs/in
13.5 N/cm |
| Adhesion to PVC (initial) | 4 lbs/in
7 N/cm |
| Adhesion to PVC (after 14 days) | 6.28 lbs/in
11 N/cm |
| Adhesion to PVC (covered side, initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PVC (covered side, after 14 days) | 7.99 lbs/in
14 N/cm |
| Adhesion to Steel (initial) | 5.48 lbs/in
9.6 N/cm |
| Adhesion to Steel (after 14 days) | 6.57 lbs/in
11.5 N/cm |
| Adhesion to Steel (covered side, after 14 days) | 8.28 lbs/in
14.5 N/cm |
| Adhesion to Steel (covered side, initial) | 7.59 lbs/in
13.3 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) | 5.42 lbs/in
9.5 N/cm |
| Adhesion to ABS (after 14 days) | 5.71 lbs/in
10 N/cm |
| Adhesion to ABS (covered side, after 14 days) | 7.42 lbs/in
13 N/cm |
| Adhesion to ABS (covered side, initial) | 6.85 lbs/in
12 N/cm |
| Adhesion to Aluminium (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to Aluminium (after 14 days) | 5.42 lbs/in
9.5 N/cm |
| Adhesion to Aluminium (covered side, after 14 days) | 7.14 lbs/in
12.5 N/cm |
| Adhesion to Aluminium (covered side, initial) | 6.85 lbs/in
12 N/cm |
| Adhesion to PC (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PC (after 14 days) | 6.85 lbs/in
12 N/cm |
| Adhesion to PC (covered side, initial) | 7.42 lbs/in
13 N/cm |
| Adhesion to PC (covered side, after 14 days) | 8.57 lbs/in
15 N/cm |
| Adhesion to PE (initial) | 3.71 lbs/in
6.5 N/cm |
| Adhesion to PE (after 14 days) | 4 lbs/in
7 N/cm |
| Adhesion to PE (covered side, after 14 days) | 4.57 lbs/in
8 N/cm |
| Adhesion to PE (covered side, initial) | 4 lbs/in
7 N/cm |
| Adhesion to PET (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PET (after 14 days) | 5.42 lbs/in
9.5 N/cm |
| Adhesion to PET (covered side, after 14 days) | 6 lbs/in
10.5 N/cm |
| Adhesion to PET (covered side, initial) | 5.71 lbs/in
10 N/cm |
| Adhesion to PP (initial) | 4 lbs/in
7 N/cm |
| Adhesion to PP (after 14 days) | 4.57 lbs/in
8 N/cm |
| Adhesion to PP (covered side, after 14 days) | 4.85 lbs/in
8.5 N/cm |
| Adhesion to PP (covered side, initial) | 4.57 lbs/in
8 N/cm |
| Adhesion to PS (initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PS (after 14 days) | 6.28 lbs/in
11 N/cm |
| Adhesion to PS (covered side, initial) | 6.85 lbs/in
12 N/cm |
| Adhesion to PS (covered side, after 14 days) | 7.71 lbs/in
13.5 N/cm |
| Adhesion to PVC (initial) | 4 lbs/in
7 N/cm |
| Adhesion to PVC (after 14 days) | 6.28 lbs/in
11 N/cm |
| Adhesion to PVC (covered side, initial) | 5.14 lbs/in
9 N/cm |
| Adhesion to PVC (covered side, after 14 days) | 7.99 lbs/in
14 N/cm |
| Adhesion to Steel (initial) | 5.48 lbs/in
9.6 N/cm |
| Adhesion to Steel (after 14 days) | 6.57 lbs/in
11.5 N/cm |
| Adhesion to Steel (covered side, after 14 days) | 8.28 lbs/in
14.5 N/cm |
| Adhesion to Steel (covered side, initial) | 7.59 lbs/in
13.3 N/cm |
Certificates
- tesa® 51865 Next Gen – Team 4965 Differential contains a 90% recycled PET backing
- resulting in an average of 6% post-consumer recycled content (including red MOPP liner) in the tape. This is a third-party environmental claim validated against the UL Environmental Claim Validation Procedure 2809 for recycled content. The UL Environmental Claim Validation Program falls under UL’s ISO/IEC17025 accreditation.
Additional Info
Liner variants:
- PV2: brown glassine paper (78μm / 3.1 mils; 90g/m²)
- PV6: red MOPP-film (80μm / 3.2 mils; 72g/m²)
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
