Product Construction
| Adhesive Type | rubber based |
| Backing material | PET fleece |
| Total thickness | 8.27 mils
210 µm |
tesa® Sleeve 51608 PV8
PET fleece sleeve for enhanced flexibility of wire harnesses
Product description
tesa Sleeve® 51608 PV8 is a single layer PET fleece edge coated with rubber adhesive for lengthwise application. It is designed for passenger compartment wire harnessing applications requiring maximum flexibility. The unique adhesive-to-adhesive closure system guarantees a secure bonding.
tesa Sleeve® 51608 PV8 features
- Very high flexibility and conformability
- Good sound suppression
- Easy and efficient lengthwise application
Product details and specifications
Application Fields
tesa Sleeve® 51608 PV8 has been developed for bundling passenger compartment wire harness areas subject to high requirements for both noise damping and harness flexibility.
Product Construction
| Adhesive Type | rubber based |
| Backing material | PET fleece |
| Total thickness | 8.27 mils
210 µm |
Properties / Performance Values
| Abrasion resistance (10mm mandrel, LV312) | Class A |
| Temperature resistance max. | 221 °F
105 °C |
| Abrasion resistance (5mm mandrel, LV312) | Class A |
| Temperature resistance min. | -40 °F
-40 °C |
| Noise damping (LV312) | Class C |
Properties / Performance Values
| Abrasion resistance (10mm mandrel, LV312) | Class A |
| Temperature resistance max. | 221 °F
105 °C |
| Abrasion resistance (5mm mandrel, LV312) | Class A |
| Temperature resistance min. | -40 °F
-40 °C |
| Noise damping (LV312) | Class C |
Adhesion to Values
| Adhesion to Steel | 1.71 lbs/in
3 N/cm |
Adhesion to Values
| Adhesion to Steel | 1.71 lbs/in
3 N/cm |
Additional Info
Also available with perforation.
Harness diameter / tesa Sleeve width recommendation
Ø 12 mm to 18 mm / 80mm
Ø 18 mm to 25 mm / 100mm
Ø 25 mm to 35 mm / 130mm
Ø 35 mm to 50 mm / 180mm
Ø 50 mm to 72 mm / 250mm
Ø 70 mm to 88 mm / 300mm
Harness diameter / tesa Sleeve width recommendation
Ø 12 mm to 18 mm / 80mm
Ø 18 mm to 25 mm / 100mm
Ø 25 mm to 35 mm / 130mm
Ø 35 mm to 50 mm / 180mm
Ø 50 mm to 72 mm / 250mm
Ø 70 mm to 88 mm / 300mm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
