Product Construction
| Adhesive Type | acrylic |
| Backing material | aluminium laminated glasscloth |
| Total thickness | 210 µm |
tesa® 68000 PV1
Aluminum laminated glass cloth tape for radiant heat reflection in the automotive engine compartment
Product Features
- Superior radiant heat reflection
- High temperature resistance
- High flexibility
Product description
tesa® 68000 PV1 is an aluminum laminated glass cloth tape with an advanced acrylic adhesive, designed for the automotive engine compartment. Its acrylic adhesive is compatible with new halogen-free cable jacketing materials (PE/PP) and provides excellent radiant heat shielding as well as enhanced durability at high temperature.
Customized length-specific kiss cutting is available on request.
Product details and specifications
Product Features
- Superior radiant heat reflection
- High temperature resistance
- High flexibility
- Ageing-resistant
- Resistant to environmental influences
- Self extinguishing
- Flexible and smooth
Application Fields
tesa® 68000 PV1 has been developed for bundling and wire protection in areas with increased demands for radiant heat protection. The major application field is wire harness segment shielding against radiant heat sources in the automotive engine compartment.
Product Construction
| Adhesive Type | acrylic |
| Backing material | aluminium laminated glasscloth |
| Total thickness | 210 µm |
Properties / Performance Values
| Elongation at break | 4 % |
| Tensile strength | 270 N/cm |
| Noise damping (LV312) | Class B |
| Temperature resistance max. | 150 °C |
Properties / Performance Values
| Elongation at break | 4 % |
| Tensile strength | 270 N/cm |
| Noise damping (LV312) | Class B |
| Temperature resistance max. | 150 °C |
Adhesion to Values
| Adhesion to Steel | 6 N/cm |
Adhesion to Values
| Adhesion to Steel | 6 N/cm |
Additional Info
1 Adhesion to steel: Backing breaks at forces greater than 6 N/cm
Standard widths: 50, 100 mm
Standard length: 50 m
- Most combinations of width and length are possible
- Also available as kiss-cut on request
- Standard core diameter: 76 mm
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
Downloads
Download the files below for more technical details and information on this product.
