Product Construction
Adhesive Type | tackified acrylic |
Backing material | PET film |
Color | black |
Color of liner | white with tesa logo |
Liner Type | glassine |
Thickness of liner | 69 µm |
Total thickness | 200 µm |
Weight of liner | 80 g/m² |
Adhesive Type | tackified acrylic |
Backing material | PET film |
Color | black |
Color of liner | white with tesa logo |
Liner Type | glassine |
Thickness of liner | 69 µm |
Total thickness | 200 µm |
Weight of liner | 80 g/m² |
Adhesive Type | tackified acrylic |
Backing material | PET film |
Color | black |
Color of liner | white with tesa logo |
Liner Type | glassine |
Thickness of liner | 69 µm |
Total thickness | 200 µm |
Weight of liner | 80 g/m² |
Elongation at break | 50 % |
Tensile strength | 20 N/cm |
Static shear resistance at 40°C | good |
Static shear resistance at 23°C | good |
Temperature resistance long term | 100 °C |
Humidity resistance | very good |
Temperature resistance short term | 200 °C |
Ageing resistance (UV) | very good |
Elongation at break | 50 % |
Tensile strength | 20 N/cm |
Static shear resistance at 40°C | good |
Static shear resistance at 23°C | good |
Temperature resistance long term | 100 °C |
Humidity resistance | very good |
Temperature resistance short term | 200 °C |
Ageing resistance (UV) | very good |
Adhesion to ABS (initial) | 10 N/cm |
Adhesion to ABS (after 14 days) | 13.3 N/cm |
Adhesion to ABS (covered side, after 14 days) | 13.5 N/cm |
Adhesion to ABS (covered side, initial) | 10.4 N/cm |
Adhesion to Glass (initial) | 14.4 N/cm |
Adhesion to Glass (after 14 days) | 16.7 N/cm |
Adhesion to PC (initial) | 11.6 N/cm |
Adhesion to PC (after 14 days) | 19.8 N/cm |
Adhesion to PC (covered side, after 14 days) | 19.5 N/cm |
Adhesion to PC (covered side, initial) | 11.6 N/cm |
Adhesion to PMMA (initial) | 14.2 N/cm |
Adhesion to PMMA (after 14 days) | 19.2 N/cm |
Adhesion to Steel (initial) | 14.3 N/cm |
Adhesion to Steel (after 14 days) | 17 N/cm |
Adhesion to Steel (covered side, after 14 days) | 17 N/cm |
Adhesion to Steel (covered side, initial) | 14.8 N/cm |
Adhesion to ABS (initial) | 10 N/cm |
Adhesion to ABS (after 14 days) | 13.3 N/cm |
Adhesion to ABS (covered side, after 14 days) | 13.5 N/cm |
Adhesion to ABS (covered side, initial) | 10.4 N/cm |
Adhesion to Glass (initial) | 14.4 N/cm |
Adhesion to Glass (after 14 days) | 16.7 N/cm |
Adhesion to PC (initial) | 11.6 N/cm |
Adhesion to PC (after 14 days) | 19.8 N/cm |
Adhesion to PC (covered side, after 14 days) | 19.5 N/cm |
Adhesion to PC (covered side, initial) | 11.6 N/cm |
Adhesion to PMMA (initial) | 14.2 N/cm |
Adhesion to PMMA (after 14 days) | 19.2 N/cm |
Adhesion to Steel (initial) | 14.3 N/cm |
Adhesion to Steel (after 14 days) | 17 N/cm |
Adhesion to Steel (covered side, after 14 days) | 17 N/cm |
Adhesion to Steel (covered side, initial) | 14.8 N/cm |
Download the files below for more technical details and information on this product.
