Product Construction
Adhesive Type | tackified acrylic |
Backing material | PE foam |
Color | black |
Liner Type | PET film |
Total thickness | 200 µm |
Adhesive Type | tackified acrylic |
Backing material | PE foam |
Color | black |
Liner Type | PET film |
Total thickness | 200 µm |
Adhesive Type | tackified acrylic |
Backing material | PE foam |
Color | black |
Liner Type | PET film |
Total thickness | 200 µm |
Elongation at break | 340 % |
Tensile strength | 6.7 N/cm |
Static shear resistance at 23°C | good |
Static shear resistance at 40°C | good |
Elongation at break | 340 % |
Tensile strength | 6.7 N/cm |
Static shear resistance at 23°C | good |
Static shear resistance at 40°C | good |
Adhesion to ABS (initial) | 11 N/cm |
Adhesion to ABS (after 14 days) | 14.5 N/cm |
Adhesion to Aluminium (initial) | 11.8 N/cm |
Adhesion to Aluminium (after 14 days) | 13.5 N/cm |
Adhesion to Glass (initial) | 15 N/cm |
Adhesion to Glass (after 14 days) | 16 N/cm |
Adhesion to PC (initial) | 14.5 N/cm |
Adhesion to PC (after 14 days) | 16 N/cm |
Adhesion to PMMA (initial) | 15.8 N/cm |
Adhesion to PMMA (after 14 days) | 16.5 N/cm |
Adhesion to Steel (initial) | 13 N/cm |
Adhesion to Steel (after 14 days) | 16 N/cm |
Adhesion to ABS (initial) | 11 N/cm |
Adhesion to ABS (after 14 days) | 14.5 N/cm |
Adhesion to Aluminium (initial) | 11.8 N/cm |
Adhesion to Aluminium (after 14 days) | 13.5 N/cm |
Adhesion to Glass (initial) | 15 N/cm |
Adhesion to Glass (after 14 days) | 16 N/cm |
Adhesion to PC (initial) | 14.5 N/cm |
Adhesion to PC (after 14 days) | 16 N/cm |
Adhesion to PMMA (initial) | 15.8 N/cm |
Adhesion to PMMA (after 14 days) | 16.5 N/cm |
Adhesion to Steel (initial) | 13 N/cm |
Adhesion to Steel (after 14 days) | 16 N/cm |
Download the files below for more technical details and information on this product.
