Product Construction
Backing material | PVC film |
Color | transparent |
Total thickness | 4.21 mils
107 µm |
Type of adhesive | natural rubber |
Double-sided transparent film tape
tesa® 4963 is a transparent double-sided self-adhesive tape, consisting of a PVC-carrier and a rubber adhesive mass system.
tesa® 4963 is largely resistant to plasticizers.
tesa® 4963 is also available in spools with an extended liner acting as "fingerlift" thus allowing easy removal of the liner.
Backing material | PVC film |
Color | transparent |
Total thickness | 4.21 mils
107 µm |
Type of adhesive | natural rubber |
Backing material | PVC film |
Color | transparent |
Total thickness | 4.21 mils
107 µm |
Type of adhesive | natural rubber |
Elongation at break | 30 % |
Tensile strength | 28.55 lbs/in
50 N/cm |
Temperature resistance short term | 158 °F
70 °C |
Static shear resistance at 40°C | good |
Chemical resistance | low |
Ageing resistance (UV) | low |
Softener resistance | medium |
Tack | good |
Humidity resistance | very good |
Elongation at break | 30 % |
Tensile strength | 28.55 lbs/in
50 N/cm |
Temperature resistance short term | 158 °F
70 °C |
Static shear resistance at 40°C | good |
Chemical resistance | low |
Ageing resistance (UV) | low |
Softener resistance | medium |
Tack | good |
Humidity resistance | very good |
Adhesion to ABS (initial) | 3.08 lbs/in
5.4 N/cm |
Adhesion to ABS (after 14 days) | 3.54 lbs/in
6.2 N/cm |
Adhesion to Aluminium (initial) | 2.28 lbs/in
4 N/cm |
Adhesion to Aluminium (after 14 days) | 2.97 lbs/in
5.2 N/cm |
Adhesion to PC (initial) | 3.54 lbs/in
6.2 N/cm |
Adhesion to PC (after 14 days) | 3.77 lbs/in
6.6 N/cm |
Adhesion to PE (initial) | 2.17 lbs/in
3.8 N/cm |
Adhesion to PE (after 14 days) | 2.57 lbs/in
4.5 N/cm |
Adhesion to PET (initial) | 2.97 lbs/in
5.2 N/cm |
Adhesion to PET (after 14 days) | 3.08 lbs/in
5.4 N/cm |
Adhesion to PP (initial) | 2.46 lbs/in
4.3 N/cm |
Adhesion to PP (after 14 days) | 3.77 lbs/in
6.6 N/cm |
Adhesion to PS (initial) | 3.03 lbs/in
5.3 N/cm |
Adhesion to PS (after 14 days) | 3.77 lbs/in
6.6 N/cm |
Adhesion to PVC (initial) | 2.86 lbs/in
5 N/cm |
Adhesion to PVC (after 14 days) | 3.37 lbs/in
5.9 N/cm |
Adhesion to Steel (initial) | 3.37 lbs/in
5.9 N/cm |
Adhesion to Steel (after 14 days) | 3.48 lbs/in
6.1 N/cm |
Adhesion to ABS (initial) | 3.08 lbs/in
5.4 N/cm |
Adhesion to ABS (after 14 days) | 3.54 lbs/in
6.2 N/cm |
Adhesion to Aluminium (initial) | 2.28 lbs/in
4 N/cm |
Adhesion to Aluminium (after 14 days) | 2.97 lbs/in
5.2 N/cm |
Adhesion to PC (initial) | 3.54 lbs/in
6.2 N/cm |
Adhesion to PC (after 14 days) | 3.77 lbs/in
6.6 N/cm |
Adhesion to PE (initial) | 2.17 lbs/in
3.8 N/cm |
Adhesion to PE (after 14 days) | 2.57 lbs/in
4.5 N/cm |
Adhesion to PET (initial) | 2.97 lbs/in
5.2 N/cm |
Adhesion to PET (after 14 days) | 3.08 lbs/in
5.4 N/cm |
Adhesion to PP (initial) | 2.46 lbs/in
4.3 N/cm |
Adhesion to PP (after 14 days) | 3.77 lbs/in
6.6 N/cm |
Adhesion to PS (initial) | 3.03 lbs/in
5.3 N/cm |
Adhesion to PS (after 14 days) | 3.77 lbs/in
6.6 N/cm |
Adhesion to PVC (initial) | 2.86 lbs/in
5 N/cm |
Adhesion to PVC (after 14 days) | 3.37 lbs/in
5.9 N/cm |
Adhesion to Steel (initial) | 3.37 lbs/in
5.9 N/cm |
Adhesion to Steel (after 14 days) | 3.48 lbs/in
6.1 N/cm |
Download the files below for more technical details and information on this product.
