Product Construction
Adhesive Type | tackified acrylic |
Backing material | PE foam |
Color | black |
Liner Type | paper |
Total thickness | 31.5 mils
800 µm |
Adhesive Type | tackified acrylic |
Backing material | PE foam |
Color | black |
Liner Type | paper |
Total thickness | 31.5 mils
800 µm |
Adhesive Type | tackified acrylic |
Backing material | PE foam |
Color | black |
Liner Type | paper |
Total thickness | 31.5 mils
800 µm |
Elongation at break | 190 % |
Tensile strength | 4.57 lbs/in
8 N/cm |
Static shear resistance at 70°C | good |
Ageing resistance (UV) | good |
Static shear resistance at 23°C | very good |
Humidity resistance | good |
Temperature resistance short term | 176 °F
80 °C |
Tack | very good |
Temperature resistance long term | 176 °F
80 °C |
Elongation at break | 190 % |
Tensile strength | 4.57 lbs/in
8 N/cm |
Static shear resistance at 70°C | good |
Ageing resistance (UV) | good |
Static shear resistance at 23°C | very good |
Humidity resistance | good |
Temperature resistance short term | 176 °F
80 °C |
Tack | very good |
Temperature resistance long term | 176 °F
80 °C |
Adhesion to ABS (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to ABS (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to PC (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to PC (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to PET (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to PET (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to PP (initial) | 0.97 lbs/in
1.7 N/cm |
Adhesion to PP (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to Steel (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to Steel (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to ABS (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to ABS (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to PC (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to PC (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to PET (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to PET (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to PP (initial) | 0.97 lbs/in
1.7 N/cm |
Adhesion to PP (after 14 days) | 5.71 lbs/in
10 N/cm |
Adhesion to Steel (initial) | 5.71 lbs/in
10 N/cm |
Adhesion to Steel (after 14 days) | 5.71 lbs/in
10 N/cm |
Download the files below for more technical details and information on this product.
