Product Construction
| Backing material | PVC film |
| Total thickness | 110 µm |
| Type of adhesive | natural rubber |
tesa® 4244 PV0
Fineline tape for design painting
Product description
tesa® 4244 is a flexible soft PVC tape with a natural rubber adhesive for fineline masking if a very sharp paint edge is required, especially on painted or unpainted plastic parts and for multi-colour painting.
- no shrinking at high temperatures
- conforms to the dimensional change during oven-drying
- no edge lifting off and removable without leaving any residues
- good conformability to multi dimensional surfaces
Product details and specifications
Application Fields
Masking & Design, for wide range of fineline applications
Product Construction
| Backing material | PVC film |
| Total thickness | 110 µm |
| Type of adhesive | natural rubber |
Properties / Performance Values
| Elongation at break | 237 % |
| Tensile strength | 27 N/cm |
| Hand tearability | very good |
| Flame retardance | very good |
| Easy to remove | yes |
| Suitable for die cutting | yes |
Properties / Performance Values
| Elongation at break | 237 % |
| Tensile strength | 27 N/cm |
| Hand tearability | very good |
| Flame retardance | very good |
| Easy to remove | yes |
| Suitable for die cutting | yes |
Adhesion to Values
| Adhesion to steel | 3.7 N/cm |
Adhesion to Values
| Adhesion to steel | 3.7 N/cm |
Additional Info
tesa® 4244 is also available for converting and die-cutting with a paper liner 4244 PV4:
adhesion to steel = 4,7 N/cm
peel off force from liner = 14 cN/cm,
die cuts are available as tesa® 54244
adhesion to steel = 4,7 N/cm
peel off force from liner = 14 cN/cm,
die cuts are available as tesa® 54244
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
