tesa® 60248

500µm single sided grey electrically conductive foam tape

Product description

tesa® 60248 is a grey single sided electrically conductive self adhesive foam tape. It consist of a perforated foam with electrically conductive coating and an electrically conductive adhesive.

tesa® 60246 features especially:

Thickness: 500µm
Excellent electrical conductivity in XYZ-direction even at high temperatures and humidity
High adhesion level even at harsh environmental conditions
Very good shock absorbing and cushioning properties
High stability of the foam to avoid flaking of particles

Product details and specifications

Application Fields

EMI shielding and grounding applications
Electrostatic discharge applications

tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.

Downloads

Download the files below for more technical details and information on this product.

Product information_tesa® 60248_en-SG 41.5 kB

Contact us

Thank you for your message

We'll get back to you as soon as possible.

Best regards

Your tesa Team

Something went wrong. Please try again later.

Backing material	conductive foam
Color	grey
Colour of liner	white/blue logo
Thickness of liner	120 µm
Total thickness	500 µm
Type of adhesive	conductive acrylic
Type of liner	PE-coated paper

Backing material	conductive foam
Color	grey
Colour of liner	white/blue logo
Thickness of liner	120 µm
Total thickness	500 µm
Type of adhesive	conductive acrylic
Type of liner	PE-coated paper

Temperature resistance short term	160 °C
Surface resistance x-y-direction	0.2 Ohm / square
Contact resistance z-direction (initial)	0.03 Ohm / square inch
Release of liner	easy

Temperature resistance short term	160 °C
Surface resistance x-y-direction	0.2 Ohm / square
Contact resistance z-direction (initial)	0.03 Ohm / square inch
Release of liner	easy

Name of product	tesa® 60248	tesa® 60685	tesa® 60231	tesa® 60215	tesa® 60217	tesa® 60218	tesa® 60276	tesa® 60571	tesa® 60233	tesa® 60249	tesa® 60333	tesa® 60210
Total thickness	500 µm	500 µm	25 µm	500 µm	1500 µm	2000 µm	200 µm			700 µm	30 µm	700 µm
Type of adhesive	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic	conductive acrylic
Backing material	conductive foam	conductive foam	conductive non-woven	conductive foam	conductive foam	conductive foam	conductive woven	conductive non-woven	Black PET / alu foil / conductive non-woven	conductive foam	black-coated copper	conductive foam
Temperature resistance short term	160 °C	200 °C	200 °C	200 °C	200 °C	200 °C	160 °C	180 °C	200 °C	160 °C		200 °C
Thickness of liner	120 µm	120 µm	50 µm	120 µm	120 µm	120 µm	120 µm	50 µm	50 µm	120 µm	100 µm	120 µm
Type of liner	PE-coated paper	PE-coated paper	PET	PE-coated paper	PE-coated paper	PE-coated paper	PE-coated paper	PET	PE-coated paper	PE-coated paper	PET film	PE-coated paper
Type of liner	type: PE-coated paper	type: PE-coated paper	type: PET	type: PE-coated paper	type: PE-coated paper	type: PE-coated paper	type: PE-coated paper	type: PET	type: PE-coated paper	type: PE-coated paper	type: PET film	type: PE-coated paper
