Product Construction
| Backing material | none |
| Color | transparent |
| Colour of liner | brown/blue logo |
| Thickness of liner | 71 µm |
| Thickness of tape | 220 µm |
| Type of adhesive | water-based acrylic |
| Type of liner | glassine |
tesa® 66022 low VOC
220µm reinforced water based acrylic adhesive layer with PET scrim for mounting in automotive interiors
Product description
tesa® 66022 is a conformable transparent adhesive layer of water based acrylic reinforced with a PET scrim mesh.
Features:
1 very low total VOC values and no critical substances detectable
1 high initial tack and peel adhesion
1 high conformable design following 3D shapes
1 provides excellent conformability and stability
1 provides excellent initial adhesion to a wide variety of interior substrates
1 suitable for the bonding to nonpolar plastics, foams, felts and fabrics
1 suitable for a certain gap filling due to thick adhesive layer
1 reliable adhesion performance for the whole vehicle life time
1 the scrim provides a reinforcement of flexible substrates for improving converting efficiency and handling
Product details and specifications
Application Fields
immediate secure fixation of light, stiff, rigid, rough parts in vertical and horizontal position
e.g. energy absorber mounting (HIC, crash pad ...)
mounting of plastics as well LSE plastics
1 with difficult wet-out
1 permanent low load
Lamination or mounting of critical, soft, light and smooth surfaces / sheets
1 immediate and secure bending around the edge
e.g. energy absorber mounting (HIC, crash pad ...)
mounting of plastics as well LSE plastics
1 with difficult wet-out
1 permanent low load
Lamination or mounting of critical, soft, light and smooth surfaces / sheets
1 immediate and secure bending around the edge
Product Construction
| Backing material | none |
| Color | transparent |
| Colour of liner | brown/blue logo |
| Thickness of liner | 71 µm |
| Thickness of tape | 220 µm |
| Type of adhesive | water-based acrylic |
| Type of liner | glassine |
Properties / Performance Values
| Fogging | very good |
| Suitable for rough surfaces | very good |
| Temperature resistance max. | 200 °C |
| Low VOC | very good |
| Suitable for die cutting | yes |
| Temperature resistance min. | -40 °C |
| Tack | very good |
Properties / Performance Values
| Fogging | very good |
| Suitable for rough surfaces | very good |
| Temperature resistance max. | 200 °C |
| Low VOC | very good |
| Suitable for die cutting | yes |
| Temperature resistance min. | -40 °C |
| Tack | very good |
Adhesion to Values
| Adhesion to ABS (initial) | 17 N/cm |
| Adhesion to ABS (after 3 days) | 18 N/cm |
| Adhesion to PC (initial) | 19.1 N/cm |
| Adhesion to PC (after 3 days) | 19.4 N/cm |
| Adhesion to PE (initial) | 9.2 N/cm |
| Adhesion to PE (after 3 days) | 9 N/cm |
| Adhesion to PET (initial) | 16.2 N/cm |
| Adhesion to PET (after 3 days) | 18.1 N/cm |
| Adhesion to PET fleece Headliner A (after 3 days) | 8 N/cm |
| Adhesion to PET fleece Headliner A (initial) | 6 N/cm |
| Adhesion to PP (initial) | 14 N/cm |
| Adhesion to PP (after 3 days) | 16 N/cm |
| Adhesion to PS (initial) | 17.7 N/cm |
| Adhesion to PS (after 3 days) | 18.2 N/cm |
| Adhesion to PVC (initial) | 12 N/cm |
| Adhesion to PVC (after 3 days) | 19.3 N/cm |
| Adhesion to Steel (initial) | 12.3 N/cm |
| Adhesion to Steel (after 3 days) | 17.3 N/cm |
Adhesion to Values
| Adhesion to ABS (initial) | 17 N/cm |
| Adhesion to ABS (after 3 days) | 18 N/cm |
| Adhesion to PC (initial) | 19.1 N/cm |
| Adhesion to PC (after 3 days) | 19.4 N/cm |
| Adhesion to PE (initial) | 9.2 N/cm |
| Adhesion to PE (after 3 days) | 9 N/cm |
| Adhesion to PET (initial) | 16.2 N/cm |
| Adhesion to PET (after 3 days) | 18.1 N/cm |
| Adhesion to PET fleece Headliner A (after 3 days) | 8 N/cm |
| Adhesion to PET fleece Headliner A (initial) | 6 N/cm |
| Adhesion to PP (initial) | 14 N/cm |
| Adhesion to PP (after 3 days) | 16 N/cm |
| Adhesion to PS (initial) | 17.7 N/cm |
| Adhesion to PS (after 3 days) | 18.2 N/cm |
| Adhesion to PVC (initial) | 12 N/cm |
| Adhesion to PVC (after 3 days) | 19.3 N/cm |
| Adhesion to Steel (initial) | 12.3 N/cm |
| Adhesion to Steel (after 3 days) | 17.3 N/cm |
Additional Info
Is designed to fulfill the low VOC (Volatile Organic Compounds) automotive requirements set forth by the Japanese Ministry of Health, Labor and Welfare (MHLW) and the Japanese Automobile Manufacturers Association (JAMA) limit of concentrations of 13 toxic chemistries. Acc. Toyota TSK0508G our assortment is conform Japanese automotive requirements
Adhesion vaules to:
PVC
PP
ABS
PC
PET
PS
PE
Are not part of the product specification
PV20 brown glassine liner / blue tesa logo
other liner version possible - on request
Adhesion vaules to:
PVC
PP
ABS
PC
PET
PS
PE
Are not part of the product specification
PV20 brown glassine liner / blue tesa logo
other liner version possible - on request
tesa® products prove their impressive quality day in, day out in demanding conditions and are regularly subjected to strict controls. All technical information and data above mentioned are provided to the best of our knowledge on the basis of our practical experience. They shall be considered as average values and are not appropriate for a specification. Therefore tesa SE can make no warranties, expressed or implied, including, but not limited to any implied warranty of merchantability or fitness for a particular purpose. The user is responsible for determining whether the tesa® product is fit for a particular purpose and suitable for the user’s method of application. If you are in any doubt, our technical staff will be glad to support you.
